Elite Power 5kWh and 10kWh LiFePO4 battery pack is engineered to deliver superior quality, safety, serviceability, and compatibility. Key features include:
Equipped with 16 high-performance cells that are securely fastened, serviceable, and replaceable.
Retains 80% State of Charge (SOC) after 3,000 cycles (80% Depth of Discharge at 0.5C rate, 25°C). Typical lifespan ranges from 4,000 to 8,000 cycles.
Designed for a typical 20-year lifespan and backed by a 5-year warranty.
Provides 48 volts (51.2V nominal) at 184Ah, delivering 9.42 kWh of energy.
Built-in BMS ensures automated, maintenance-free operation with advanced protection features.
Equipped with 5 temperature sensors to safeguard against extreme temperatures.
Prevents potential BMS damage during operation.
Includes 16 flame-retardant cell holders for stable structural support, enhanced heat dissipation, and improved cell performance.
Detachable and replaceable components, including the cover, BMS, cells, and holders, ensure easy servicing.
RS485 and CAN Bus protocols are built-in and upgradable, making the battery compatible with most inverters. (Ensure proper communication cables are used.)
Suitable for wall or floor mounting for convenient setup.
Monitor performance through a mobile app with Bluetooth.
| Model | 48V100Ah | 48V200Ah |
| Size (L x W x H) | 460 * 195 * 660 mm | 460 * 195 * 995 mm |
| Nominal Voltage/Capacity | 51.2V 100Ah | 51.2V 200Ah |
| Energy | 5120Wh | 10240Wh |
| Maximum Output Power (Instant) | 5120W | 10240W |
| Maximum Output Power (Continue) | 4600W | 9200W |
| Internal Resistance | ≤ 40mΩ @ 50% SOC | ≤ 35mΩ @ 50% SOC |
| Self-Discharge | < 3% per month | < 3% per month |
| Shell Material | Ironclad | Ironclad |
| Waterproof Class | IP55 | IP55 |
| Standard Charging Current | 20A | 40A |
| Maximum Charging Current | 100A | 200A |
| Charging Temperature | 0°C ~ 45°C | 0°C ~ 45°C |
| Charging Voltage | 57.6 ± 0.2V | 57.6 ± 0.2V |
| Storage Temperature | 5°C ~ 45°C | 5°C ~ 45°C |
| Maximum Discharge Current | 200A | 200A |
| Discharging Temperature | -20°C ~ 65°C | -20°C ~ 65°C |
| Overcurrent Protection | 210A | 210A |
| Protective Plate Specification | 100A | 200A |
| Bluetooth Function | Assorting | Assorting |
| RS485 Communication | Support | |
| CAN Communication | Support | |
| 232 Communication | Support | |
| Parallel Connection Mode | Support | |
| Series Connection Mode | No Serial Use | |
| Certificate | UN3480, Class 9, MSDS, RoHS | |
