| OUTPUT | Voltage (DC) | 9V | 9.1-14V | 14.1-21V | 21.1-30V | 30.1-48V |
| Current (Max.) | 5A | 4.16A | 3.36A | 2.3A | 1.57A | |
| Power (Max.) | 45W | 50W | 50.4W | 50.4W | 50.4W | |
| Ripple & Noise | ≤ 150mV | ≤ 200mV | ≤ 200mV | ≤ 300mV | ≤ 300mV | |
| Voltage Tolerance | ± 5% | |||||
| Standby Power | < 0.21W | |||||
| INPUT | Voltage Range | 100-240VAC | ||||
| Frequency Range | 50-60Hz | |||||
| ENVIRONMENT | Operation Temp. | 0°C to +40°C | ||||
| Storage Temp. | -20°C to +80°C | |||||
| Operation Hum. | 10% - 90% | |||||
| SAFETY | Safety Standards | 60601, CB, cULus, FCC, CE, TUV Mark, AU plug report | ||||
| Other | MTBF | > 50,000 hours at 80% load and 25°C | ||||
| Dimension | 84.5 x 52.0 x 35.0 mm | |||||
| The range of input voltage is from 198Vac to 264Vac with a single phase. | |
| Inrush Current (cold start) | The inrush current will not exceed 160A at 220Vac input and Max load for a cold start at 25°C. |
| Full Load Efficiency | While input 230Vac, the full load efficiency is more than 85.00%. |
| Capacitance Load | While input 220Vac CV Mode and capacitance load is 470uF, the Charger can turn on normally and the constant current is in the rated range. |
| Output Load Transient Response | The output shall not exceed 10% of the nominal output voltage, load fluctuation from 20% to 80%, R/S 0.5A/uS, frequency 100Hz duration and 8mS at 80%. |
| Over Current Point Limited | I > 3.1A. The output shall hiccup when the over currents applied to the output rail, and shall be self-recovery when the fault condition is removed. |
| Short Circuit Protection | The input power shall decrease when the output rail short, the power supply shall no damage, and shall be self-recovery when the fault condition is removed. |
| Over Voltage Protection | The power supply shall protection when the output over voltage. |
| Vibration | 10 to 300Hz sweep at a constant acceleration of 1.0G (Breadth: 3.5mm) for 1 Hour for each of the perpendicular axes X, Y, Z. |
| Burn-in | The power supply shall be burn-in at least 4 Hours under normal input and 80% rated load at 40°C ± 5°C. |
| MTBF Qualification | The MTBF shall be at least 50,000 hours at 25°C, Full load and nominal input condition. |
| AC pins corresponding to relative national standards. | |
| Dielectric Strength (Hi-pot) | Primary to Secondary: 4242VDC or 3000VAC / 5mA Max / 60 seconds (3 seconds for mass production). |
| Leakage Current | 0.25mA max. at 264Vac / 50Hz. |
| Insulation Resistance | 50MΩ min. at primary to secondary add 500Vdc test voltage. |
| PE bag, color bag, cardboard, paper case, etc. | |
Our factory designs and manufactures open frame power supplies, AC-DC power adapters, chargers, transformers, and audio power supply products. We have already launched thousands of products for applications such as audio apparatus, information and technology, telecommunication, green energy, medical, and home appliances. All of our power supply products have obtained UL/CUL, TUV, GS, PSE, CE, KC, CCC, SAA, BMSI, and other global quality and safety certifications. We are dedicated to the research and development of new products, utilizing advanced equipment to carry out rigorous tests including ESD, EMC, lightning surge, temperature rise, mechanical plug tests, and IPXX waterproof tests. Customized power supply solutions are provided for customers worldwide. Our power adapters and other power products are widely used in consumer electronics, home appliances, office equipment, medical equipment, industrial equipment, transportation, photography, video equipment, outdoor/emergency equipment, power tools, and other products.
